Architecture
Ignition Scope Distribution
How does the .modl distribute its payload across the Ignition Gateway?
-
Gateway Scope:
-
On Source gateway :
-
Configuration page
-
Status page
-
Networking Security layer
-
Listen to device(s) OPC-Tag, to OPC-UA(s) changes
-
Listen to devices & OPC-UA changes (add/remove)
-
Buffer & forward to Destination
-
-
On Destination gateway :
-
Configuration page
-
Status page
-
Networking Security layer
-
Listen to source
-
Listen to devices & OPC-UA changes (add/remove)
-
Buffer & forward to Destination
-
-
-
Designer Scope: No functionality.
-
Client/Session Scope: No functionality.
Data Flow
External Dependencies
There is no external dependencies required for this module.
